| 連接介面 | • 8× 10/100/1000 Mbps RJ45 Ports • AUTO Negotiation • AUTO MDI/MDIX |
|---|---|
| 網路連接線 | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
| 風扇數量 | Fanless |
| 物理安全鎖 | Yes |
| 外接電源供應器 | External Power Adapter(Output: 53.5VDC / 1.31A) |
| 封包轉發速率 | 11.904 Mpps |
| PoE連接埠(RJ45) | • Standard: 802.3 af/at compliant • PoE Ports: Ports 1–8 • Power Supply: 65 W |
| MAC位址表 | 4K |
| 巨型訊框 | 16 KB |
| 交換容量 | 16 Gbps |
| 尺寸(長 x 寬 x 高) | 6.2×4.0×1.0 in (158×101×25 mm) |
| 最大功耗 | • 4.59 W (220/50 Hz no PD connected) • 75.75 W (220/50 Hz with 65 W PD connected) |
| 最大散熱量 | • 15.66 BTU/h (no PD connected) • 258.46 BTU/h (with 65 W PD connected) |
